HCPL-J312-500E
Part Number:
HCPL-J312-500E
Product Classification:
Accessories - Caps
Manufacturer:
Agrowtek Inc.
Description:
OPTOISO 3.75KV 1CH GT DVR 8DIP
Packaging:
-
ROHS Status:
No
Currency:
USD
PDF:
Documents
|
Category |
Isolators
Isolators - Gate Drivers
|
|
|
Mfr |
Broadcom Limited |
|
|
Series |
-
|
|
|
Packaging |
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status |
Active
|
|
|
Technology |
Optical Coupling
|
|
|
Number of Channels |
1
|
|
|
Voltage - Isolation |
3750Vrms
|
|
|
Common Mode Transient Immunity (Min) |
25kV/µs
|
|
|
Propagation Delay tpLH / tpHL (Max) |
500ns, 500ns
|
|
|
Pulse Width Distortion (Max) |
300ns
|
|
|
Rise / Fall Time (Typ) |
100ns, 100ns
|
|
|
Current - Output High, Low |
2A, 2A
|
|
|
Current - Peak Output |
2.5A
|
|
|
Voltage - Forward (Vf) (Typ) |
1.6V
|
|
|
Current - DC Forward (If) (Max) |
25 mA
|
|
|
Voltage - Output Supply |
15V ~ 30V
|
|
|
Grade |
-
|
|
|
Qualification |
-
|
|
|
Operating Temperature |
-40°C ~ 100°C
|
|
|
Mounting Type |
Surface Mount
|
|
|
Package / Case |
8-SMD, Gull Wing
|
|
|
Supplier Device Package |
8-DIP Gull Wing
|
|
|
Approval Agency |
CSA, IEC/EN/DIN, UR
|
|
|
Base Product Number |
HCPL-J312 |
