HCPL-0600-500E

 15 kV/µs minimum Common Mode Rejection (CMR) at
VCM= 1 kV for HCNW2611, HCPL-2611, HCPL-4661,
HCPL-0611, HCPL-0661
 High speed: 10 MBd typical
 LSTTL/TTL compatible
 Low input current capability: 5 mA
 Guaranteed AC and DC performance over industrial
temperature: –40°C to +85°C
 Available in 8-Pin DIP, SOIC-8, widebody packages
 Strobable output (single channel products only)
 Safety approval
– UL recognized – 3750 Vrms for 1 minute and
5000 Vrms for 1 minute per UL1577 CSA approved
(5000 Vrms/1 Minute rating is for HCNW137/26X1
and Option 020 [6N137, HCPL-2601/11/30/31,
HCPL-4661] products only)
– IEC/EN/DIN EN 60747-5-5 approved with:
 VIORM = 567 Vpeak for 06xx Option 060
 VIORM = 630 Vpeak for 6N137/26xx Option 060
 VIORM =1414 Vpeak for HCNW137/26x1
 MIL-PRF-38534 hermetic version available
(HCPL-56xx/66xx)
