Category |
Isolators
Optocouplers, Optoisolators
Transistor, Photovoltaic Output Optoisolators
|
|
|
Manufacturer |
Broadcom Limited
|
|
|
Series |
-
|
|
|
Packaging |
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status |
Active
|
|
|
Number of Channels |
1
|
|
|
Voltage - Isolation |
5000Vrms
|
|
|
Current Transfer Ratio (Min) |
0.36% @ 10mA
|
|
|
Current Transfer Ratio (Max) |
0.72% @ 10mA
|
|
|
Turn On / Turn Off Time (Typ) |
-
|
|
|
Rise / Fall Time (Typ) |
-
|
|
|
Input Type |
DC
|
|
|
Output Type |
Photovoltaic, Linearized
|
|
|
Voltage - Output (Max) |
-
|
|
|
Current - Output / Channel |
-
|
|
|
Voltage - Forward (Vf) (Typ) |
1.6V
|
|
|
Current - DC Forward (If) (Max) |
25 mA
|
|
|
Vce Saturation (Max) |
-
|
|
|
Operating Temperature |
-55°C ~ 100°C
|
|
|
Mounting Type |
Surface Mount
|
|
|
Package / Case |
8-SMD, Gull Wing
|
|
|
Supplier Device Package |
8-DIP Gull Wing
|
|
|
Base Product Number |
HCNR201 |
