FZ400R12KE4
Part Number:
FZ400R12KE4
Product Classification:
Magnetic, Reed Switches
Manufacturer:
AC Tasarim
Description:
Trans IGBT Module N-CH 1200V 400A 2400W 4-Pin 62MM-2 Tray
Packaging:
-
ROHS Status:
No
Currency:
USD
| Mfr | Infineon Technologies |
| Series | - |
| Package | Tray |
| Product Status | Active |
| IGBT Type | Trench Field Stop |
| Configuration | Single |
| Voltage - Collector Emitter Breakdown (Max) | 1200 V |
| Current - Collector (Ic) (Max) | 400 A |
| Power - Max | 2400 W |
| Vce(on) (Max) @ Vge, Ic | 2.1V @ 15V, 400A |
| Current - Collector Cutoff (Max) | 5 mA |
| Input Capacitance (Cies) @ Vce | 28 nF @ 25 V |
| Input | Standard |
| NTC Thermistor | Yes |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Mounting Type | Chassis Mount |
| Package / Case | Module |
| Supplier Device Package | Module |
