FSA1156P6X
Part Number:
FSA1156P6X
Product Classification:
Accessories
Manufacturer:
ADDA USA
Description:
IC SWITCH SPST-NOX1 900MOHM SC88
Packaging:
-
ROHS Status:
No
Currency:
USD
PDF:
Documents
|
Category |
Integrated Circuits (ICs)
Interface
Analog Switches, Multiplexers, Demultiplexers
|
|
|
Manufacturer |
onsemi
|
|
|
Series |
-
|
|
|
Packaging |
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status |
Obsolete
|
|
|
Switch Circuit |
SPST - NO
|
|
|
Multiplexer/Demultiplexer Circuit |
1:1
|
|
|
Number of Circuits |
1
|
|
|
On-State Resistance (Max) |
900mOhm
|
|
|
Channel-to-Channel Matching (ΔRon) |
-
|
|
|
Voltage - Supply, Single (V+) |
1.65V ~ 5.5V
|
|
|
Voltage - Supply, Dual (V±) |
-
|
|
|
Switch Time (Ton, Toff) (Max) |
20ns, 30ns
|
|
|
-3db Bandwidth |
300MHz
|
|
|
Charge Injection |
20pC
|
|
|
Channel Capacitance (CS(off), CD(off)) |
20pF
|
|
|
Current - Leakage (IS(off)) (Max) |
2nA
|
|
|
Crosstalk |
-
|
|
|
Operating Temperature |
-40°C ~ 85°C (TA)
|
|
|
Mounting Type |
Surface Mount
|
|
|
Package / Case |
6-TSSOP, SC-88, SOT-363
|
|
|
Supplier Device Package |
SC-88 (SC-70-6)
|
|
|
Base Product Number |
FSA1156 |
