DPBW03F-12
Part Number:
DPBW03F-12
Product Classification:
Programmable Display Switches
Manufacturer:
Anatech Microwave Company
Description:
DC DC CONVERTER +/-12V 3W
Packaging:
-
ROHS Status:
No
Currency:
USD
PDF:
Documents
|
Category |
Power Supplies - Board Mount
DC DC Converters
|
|
|
Mfr |
MEAN WELL USA Inc. |
|
|
Series |
DPBW03 (3W) |
|
|
Packaging |
Tube
|
|
|
Part Status |
Active
|
|
|
Type |
Isolated Module
|
|
|
Number of Outputs |
2
|
|
|
Voltage - Input (Min) |
9V
|
|
|
Voltage - Input (Max) |
36V
|
|
|
Voltage - Output 1 |
12V |
|
|
Voltage - Output 2 |
-12V
|
|
|
Voltage - Output 3 |
-
|
|
|
Voltage - Output 4 |
-
|
|
|
Current - Output (Max) |
125mA, 125mA
|
|
|
Power (Watts) |
3 W
|
|
|
Voltage - Isolation |
1.5 kV
|
|
|
Applications |
ITE (Commercial)
|
|
|
Features |
Remote On/Off, OCP, SCP, UVLO
|
|
|
Operating Temperature |
-40°C ~ 85°C (With Derating)
|
|
|
Efficiency |
83%
|
|
|
Mounting Type |
Through Hole
|
|
|
Package / Case |
8-SIP Module, 7 Leads
|
|
|
Size / Dimension |
0.86" L x 0.36" W x 0.44" H (21.8mm x 9.2mm x 11.1mm)
|
|
|
Supplier Device Package |
-
|
|
|
Base Product Number |
DPBW03 |
