Category |
Connectors, Interconnects
Coaxial Connectors (RF)
Coaxial Connector (RF) Assemblies
|
|
|
Mfr |
TE Connectivity Linx |
|
|
Series |
-
|
|
|
Packaging |
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status |
Active
|
|
|
Connector Style |
I-PEX MHF4 |
|
|
Connector Type |
Jack, Male Pin
|
|
|
Contact Termination |
Solder
|
|
|
Shield Termination |
Solder
|
|
|
Impedance |
50 Ohms
|
|
|
Mounting Type |
Surface Mount
|
|
|
Mounting Feature |
-
|
|
|
Cable Group |
-
|
|
|
Fastening Type |
Snap-On
|
|
|
Frequency - Max |
6 GHz
|
|
|
Number of Ports |
1
|
|
|
Features |
-
|
|
|
Housing Color |
Black
|
|
|
Ingress Protection |
-
|
|
|
Center Contact Material |
Copper Alloy
|
|
|
Includes |
-
|
|
|
Body Material |
Copper Alloy
|
|
|
Body Finish |
Gold
|
|
|
Center Contact Plating |
Gold
|
|
|
Dielectric Material |
Liquid Crystal Polymer (LCP)
|
|
|
Operating Temperature |
-65°C ~ 165°C
|
|
|
Voltage Rating |
60 V
|
|
|
Mating Cycles |
30
|
|
|
Insertion Loss |
-
|
|
|
Base Product Number |
CONMHF |
