BLF645,112

CW performance at 1300 MHz, a drain-source voltage VDS of 32 V and a quiescent
drain current IDq = 0.9 A for total device:
 Average output power = 100 W
 Power gain = 18 dB
 Drain efficiency = 56 %
 2-tone performance at 1300 MHz, a drain-source voltage VDS of 32 V and a quiescent
drain current IDq = 0.9 A for total device:
 Peak envelope load power = 100 W
 Power gain = 18 dB
 Drain efficiency = 45 %
 Intermodulation distortion = 32 dBc
 Integrated ESD protection
 Excellent ruggedness
 High power gain
 High efficiency
 Excellent reliability
 Easy power control
 Compliant to Directive 2002/95/EC, regarding Restriction of Hazardous Substances
(RoHS)
