AX7DAF1-1030.0000
Part Number:
AX7DAF1-1030.0000
Product Classification:
AC DC Configurable Power Supply Modules
Manufacturer:
Agile MwT
Description:
XTAL OSC XO 1.0300GHZ LVDS SMD
Packaging:
-
ROHS Status:
No
Currency:
USD
PDF:
Documents
|
Category |
Crystals, Oscillators, Resonators
Oscillators
|
|
|
Mfr |
Abracon LLC |
|
|
Series |
ClearClock™ AX7 |
|
|
Packaging |
Bulk
|
|
|
Part Status |
Active
|
|
|
Base Resonator |
Crystal |
|
|
Type |
XO (Standard) |
|
|
Frequency |
1.03 GHz
|
|
|
Function |
Enable/Disable
|
|
|
Output |
LVDS
|
|
|
Voltage - Supply |
3.3V
|
|
|
Frequency Stability |
±25ppm
|
|
|
Absolute Pull Range (APR) |
-
|
|
|
Operating Temperature |
-40°C ~ 85°C
|
|
|
Current - Supply (Max) |
70mA
|
|
|
Ratings |
-
|
|
|
Mounting Type |
Surface Mount
|
|
|
Package / Case |
8-SMD, No Lead
|
|
|
Size / Dimension |
0.276" L x 0.197" W (7.00mm x 5.00mm)
|
|
|
Height - Seated (Max) |
0.075" (1.90mm)
|
|
|
Current - Supply (Disable) (Max) |
65mA
|
