ASTMHTD-100.000MHZ-AJ-E-T
Part Number:
ASTMHTD-100.000MHZ-AJ-E-T
Product Classification:
AC DC Configurable Power Supply Modules
Manufacturer:
Agile MwT
Description:
MEMS OSC XO 100.0000MHZ LVCMOS
Packaging:
-
ROHS Status:
No
Currency:
USD
PDF:
Documents
|
Category |
Crystals, Oscillators, Resonators
Oscillators
|
|
|
Mfr |
Abracon LLC |
|
|
Series |
ASTMHT |
|
|
Packaging |
Tape & Reel (TR)
Cut Tape (CT)
|
|
|
Part Status |
Obsolete
|
|
|
Base Resonator |
MEMS |
|
|
Type |
XO (Standard) |
|
|
Frequency |
100 MHz
|
|
|
Function |
Enable/Disable
|
|
|
Output |
LVCMOS
|
|
|
Voltage - Supply |
2.25V ~ 3.63V
|
|
|
Frequency Stability |
±20ppm
|
|
|
Absolute Pull Range (APR) |
-
|
|
|
Operating Temperature |
-40°C ~ 125°C
|
|
|
Current - Supply (Max) |
-
|
|
|
Ratings |
-
|
|
|
Mounting Type |
Surface Mount
|
|
|
Package / Case |
4-SMD, No Lead
|
|
|
Supplier Device Package |
4-SMD (2.5x2)
|
|
|
Size / Dimension |
0.098" L x 0.079" W (2.50mm x 2.00mm)
|
|
|
Height - Seated (Max) |
0.031" (0.80mm)
|
|
|
Current - Supply (Disable) (Max) |
-
|
