AO3400A
Part Number:
AO3400A
Product Classification:
Specialty Transformers
Manufacturer:
Alchemy Power Inc.
Description:
MOSFET N-CH 30V 5.7A SOT23-3L
Packaging:
-
ROHS Status:
No
Currency:
USD
PDF:
Documents
|
Category |
Discrete Semiconductor Products
Transistors
FETs, MOSFETs
Single FETs, MOSFETs
|
|
|
Mfr |
Alpha & Omega Semiconductor Inc. |
|
|
Series |
-
|
|
|
Packaging |
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status |
Not For New Designs
|
|
|
FET Type |
N-Channel |
|
|
Technology |
MOSFET (Metal Oxide) |
|
|
Drain to Source Voltage (Vdss) |
30 V
|
|
|
Current - Continuous Drain (Id) @ 25°C |
5.7A (Ta) |
|
|
Drive Voltage (Max Rds On, Min Rds On) |
2.5V, 10V
|
|
|
Rds On (Max) @ Id, Vgs |
26.5mOhm @ 5.7A, 10V
|
|
|
Vgs(th) (Max) @ Id |
1.5V @ 250µA
|
|
|
Gate Charge (Qg) (Max) @ Vgs |
7 nC @ 4.5 V
|
|
|
Vgs (Max) |
±12V
|
|
|
Input Capacitance (Ciss) (Max) @ Vds |
630 pF @ 15 V
|
|
|
FET Feature |
-
|
|
|
Power Dissipation (Max) |
1.4W (Ta)
|
|
|
Operating Temperature |
-55°C ~ 150°C (TJ)
|
|
|
Mounting Type |
Surface Mount
|
|
|
Supplier Device Package |
SOT-23-3
|
|
|
Package / Case |
3-SMD, SOT-23-3 Variant |
|
|
Base Product Number |
AO34 |
