AD5686RBRUZ-RL7
Part Number:
AD5686RBRUZ-RL7
Product Classification:
Isolation Transformers and Autotransformers, Step Up, Step Down
Manufacturer:
AEM Central Semiconductor
Description:
IC DAC 16BIT V-OUT 16TSSOP
Packaging:
-
ROHS Status:
No
Currency:
USD
PDF:
Documents
|
Category |
Integrated Circuits (ICs)
Data Acquisition
Digital to Analog Converters (DAC)
|
|
|
Manufacturer |
Analog Devices Inc.
|
|
|
Series |
nanoDAC+® |
|
|
Packaging |
Tape & Reel (TR)
|
|
|
Part Status |
Active
|
|
|
Number of Bits |
16
|
|
|
Number of D/A Converters |
4
|
|
|
Settling Time |
8µs
|
|
|
Output Type |
Voltage - Buffered
|
|
|
Differential Output |
No
|
|
|
Data Interface |
SPI, DSP
|
|
|
Reference Type |
External, Internal
|
|
|
Voltage - Supply, Analog |
2.7V ~ 5.5V
|
|
|
Voltage - Supply, Digital |
1.8V ~ 5.5V
|
|
|
INL/DNL (LSB) |
±1, ±1 (Max)
|
|
|
Architecture |
String DAC
|
|
|
Operating Temperature |
-40°C ~ 105°C
|
|
|
Package / Case |
16-TSSOP (0.173", 4.40mm Width)
|
|
|
Supplier Device Package |
16-TSSOP
|
|
|
Mounting Type |
Surface Mount
|
|
|
Base Product Number |
AD5686 |
