9WL0948P1F601
Part Number:
9WL0948P1F601
Product Classification:
Remote Phosphor Light Source
Manufacturer:
AEM Renaissance
Description:
Fan Tubeaxial 48VDC Square - 92mm L x 92mm H Ball 102.4 CFM (2.87m³/min) 4 Wire Leads
Packaging:
-
ROHS Status:
No
Currency:
USD
| Mfr | Sanyo Denki America Inc. |
| Series | San Ace 92W |
| Packaging | Bulk |
| Part Status | Active |
| Voltage - Rated | 48VDC |
| Size / Dimension | Square - 92mm L x 92mm H |
| Width | 38.00mm |
| Air Flow | 102.4 CFM (2.87m³/min) |
| Static Pressure | 1.050 in H2O (261.5 Pa) |
| Bearing Type | Ball |
| Fan Type | Tubeaxial |
| Features | PWM Control, Speed Sensor (Tach) |
| Noise | 55.0dB(A) |
| Power (Watts) | 11.52 W |
| RPM | 7000 RPM |
| Termination | 4 Wire Leads |
| Ingress Protection | IP68 - Dust Tight, Waterproof |
| Operating Temperature | -4 ~ 158°F (-20 ~ 70°C) |
| Approval Agency | cURus, TUV |
| Weight | 0.661 lb (299.82 g) |
| Current Rating (Amps) | 0.240A |
| Voltage Range | 40.8 ~ 52.8VDC |
| Material - Frame | Aluminum |
| Material - Blade | Plastic |
| Lifetime @ Temp. | 100000 Hrs @ 60°C |
| Base Product Number | 9WL0948 |
