78439346047
Part Number:
78439346047
Product Classification:
Pushbutton Switches - Hall Effect
Manufacturer:
Analog Technologies
Description:
WE-XHMA SMT POWER INDUCTOR 6060;
Packaging:
-
ROHS Status:
No
Currency:
USD
PDF:
Documents
|
Category |
Inductors, Coils, Chokes
Fixed Inductors
|
|
|
Mfr |
Würth Elektronik |
|
|
Series |
WE-XHMA |
|
|
Packaging |
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status |
Active
|
|
|
Type |
Drum Core, Wirewound
|
|
|
Material - Core |
Metal Composite |
|
|
Inductance |
4.7 µH
|
|
|
Tolerance |
±20%
|
|
|
Current Rating (Amps) |
7.4 A |
|
|
Current - Saturation (Isat) |
13A
|
|
|
Shielding |
Shielded
|
|
|
DC Resistance (DCR) |
13mOhm
|
|
|
Q @ Freq |
-
|
|
|
Frequency - Self Resonant |
28MHz
|
|
|
Ratings |
AEC-Q200
|
|
|
Operating Temperature |
-40°C ~ 125°C
|
|
|
Inductance Frequency - Test |
100 kHz
|
|
|
Features |
-
|
|
|
Mounting Type |
Surface Mount
|
|
|
Package / Case |
Nonstandard
|
|
|
Supplier Device Package |
-
|
|
|
Size / Dimension |
0.262" L x 0.254" W (6.65mm x 6.45mm)
|
|
|
Height - Seated (Max) |
0.240" (6.10mm)
|
