74LVC1G3157GW,125
Part Number:
74LVC1G3157GW,125
Product Classification:
Wire Cutters
Manufacturer:
Amphenol Fiber Systems International
Description:
1 Circuit IC Switch 2:1 10Ohm 6-TSSOP
Packaging:
-
ROHS Status:
No
Currency:
USD
PDF:
Documents
• Wide supply voltage range from 1.65 V to 5.5 V
• Very low ON resistance:
• 7.5 Ω (typical) at VCC = 2.7 V
• 6.5 Ω (typical) at VCC = 3.3 V
• 6 Ω (typical) at VCC = 5 V
• 32 mA continuous switch current
• Break-before-make switching
• High noise immunity
• CMOS low power dissipation
• TTL interface compatibility at 3.3 V
• Latch-up performance meets requirements of JESD 78 Class I
• Overvoltage tolerant control inputs to 5.5 V
• ESD protection:
• HBM: ANSI/ESDA/JEDEC JS-001 class 2 exceeds 2000 V
• CDM: ANSI/ESDA/JEDEC JS-002 class C3 exceeds 1000 V
• Multiple package options
• Specified from -40 °C to +85 °C and from -40 °C to +125 °C
