74HC138D,653
Part Number:
74HC138D,653
Product Classification:
Microphones
Manufacturer:
Amphenol Fiber Systems International
Description:
Decoder/Demultiplexer 1 x 3:8 16-SO
Packaging:
-
ROHS Status:
No
Currency:
USD
• Wide supply voltage range from 2.0 to 6.0 V
• CMOS low power dissipation
• High noise immunity
• Latch-up performance exceeds 100 mA per JESD 78 Class II Level B
• Demultiplexing capability
• Multiple input enable for easy expansion
• Ideal for memory chip select decoding
• Active LOW mutually exclusive outputs
• Input levels:
• For 74HC138: CMOS level
• For 74HCT138: TTL level
• Complies with JEDEC standards:
• JESD8C (2.7 V to 3.6 V)
• JESD7A (2.0 V to 6.0 V)
• ESD protection:
• HBM: ANSI/ESDA/JEDEC JS-001 class 2 exceeds 2000 V
• CDM: ANSI/ESDA/JEDEC JS-002 class C3 exceeds 1000 V
• Multiple package options
• Specified from -40 °C to +85 °C and from -40 °C to +125 °C
