74438356047
Part Number:
74438356047
Product Classification:
Pushbutton Switches - Hall Effect
Manufacturer:
Analog Technologies
Description:
4.7 µH Shielded Molded Inductor 2.9 A 76mOhm Max 1616 (4040 Metric)
Packaging:
-
ROHS Status:
No
Currency:
USD
PDF:
Documents
|
Mfr |
|
|
|
Series |
|
|
|
Packaging |
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status |
Active
|
|
|
Type |
Molded
|
|
|
Material - Core |
|
|
|
Inductance |
4.7 µH
|
|
|
Tolerance |
±20%
|
|
|
Current Rating (Amps) |
|
|
|
Current - Saturation (Isat) |
4.7A
|
|
|
Shielding |
Shielded
|
|
|
DC Resistance (DCR) |
76mOhm Max
|
|
|
Q @ Freq |
-
|
|
|
Frequency - Self Resonant |
22MHz
|
|
|
Ratings |
AEC-Q200
|
|
|
Operating Temperature |
-40°C ~ 125°C
|
|
|
Inductance Frequency - Test |
100 kHz
|
|
|
Mounting Type |
Surface Mount
|
|
|
Package / Case |
1616 (4040 Metric)
|
|
|
Supplier Device Package |
4020
|
|
|
Size / Dimension |
0.161" L x 0.161" W (4.10mm x 4.10mm)
|
|
|
Height - Seated (Max) |
0.083" (2.10mm)
|
