62674-261121ALF
Part Number:
62674-261121ALF
Product Classification:
External/Internal Power Supply Accessories
Manufacturer:
Aven
Description:
26 Position FFC, FPC Connector Contacts, Vertical - 1 Sided 0.020" (0.50mm) Surface Mount
Packaging:
-
ROHS Status:
No
Currency:
USD
PDF:
Documents
| Manufacturer | Amphenol ICC (FCI) |
| Series | SFV-S |
| Packaging | Tape & Reel (TR) |
| Cut Tape (CT) | |
| Part Status | Obsolete |
| Flat Flex Type | FFC, FPC |
| Mounting Type | Surface Mount |
| Connector/Contact Type | Contacts, Vertical - 1 Sided |
| Number of Positions | 26 |
| Pitch | 0.020" (0.50mm) |
| Termination | Kinked Pin |
| FFC, FCB Thickness | 0.30mm |
| Height Above Board | 0.161" (4.10mm) |
| Locking Feature | - |
| Cable End Type | Straight or Tapered |
| Contact Material | Phosphor Bronze |
| Contact Finish | Gold |
| Housing Material | Plastic, Glass Filled |
| Actuator Material | Plastic, Glass Filled |
| Features | Zero Insertion Force (ZIF) |
| Voltage Rating | 50V |
| Operating Temperature | -55°C ~ 105°C |
| Material Flammability Rating | UL94 V-0 |
| Current Rating (Amps) | 0.5A |
| Contact Finish Thickness | - |
| Housing Color | Black |
| Actuator Color | - |
| Mating Cycles | 20 |
| Base Product Number | 62674 |
