2SC1815
Part Number:
2SC1815
Product Classification:
Specialty Transformers
Manufacturer:
ams OSRAM
Description:
Bipolar (BJT) Transistor NPN 50 V 150 mA 80MHz 400 mW Through Hole TO-92
Packaging:
-
ROHS Status:
No
Currency:
USD
| Mfr | Lumimax Optoelectronic Technology |
| Series | - |
| Packaging | Bulk |
| Part Status | Active |
| Transistor Type | NPN |
| Current - Collector (Ic) (Max) | 150 mA |
| Voltage - Collector Emitter Breakdown (Max) | 50 V |
| Vce Saturation (Max) @ Ib, Ic | 250mV @ 10mA, 100mA |
| Current - Collector Cutoff (Max) | 0.1µA (ICBO) |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 70 @ 2mA, 6V |
| Power - Max | 400 mW |
| Frequency - Transition | 80MHz |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Through Hole |
| Package / Case | TO-226-3, TO-92-3 (TO-226AA) |
| Supplier Device Package | TO-92 |
