174973-2
Part Number:
174973-2
Product Classification:
Excavators, Hooks, Picks, Probes, Tuning Tools
Manufacturer:
Cinch Connectivity Solutions
Description:
CONN HEADER VERT 12POS 2.5MM
Packaging:
-
ROHS Status:
No
Currency:
USD
PDF:
Documents
|
Category |
Connectors, Interconnects
Rectangular Connectors
Headers, Male Pins
|
|
|
Mfr |
TE Connectivity AMP Connectors |
|
|
Series |
Multi-Lock |
|
|
Packaging |
Tray
|
|
|
Part Status |
Active
|
|
|
Connector Type |
-
|
|
|
Contact Type |
Tab
|
|
|
Pitch - Mating |
0.098" (2.50mm) |
|
|
Number of Positions |
12 |
|
|
Number of Rows |
2
|
|
|
Row Spacing - Mating |
0.205" (5.20mm) |
|
|
Number of Positions Loaded |
All
|
|
|
Style |
Board to Cable/Wire |
|
|
Shrouding |
Shrouded - 4 Wall
|
|
|
Mounting Type |
Through Hole |
|
|
Termination |
Solder
|
|
|
Fastening Type |
Locking Ramp
|
|
|
Contact Length - Mating |
0.276" (7.00mm)
|
|
|
Contact Length - Post |
0.146" (3.70mm)
|
|
|
Overall Contact Length |
-
|
|
|
Insulation Height |
0.756" (19.20mm)
|
|
|
Contact Shape |
Rectangular
|
|
|
Contact Finish - Mating |
Tin
|
|
|
Contact Finish Thickness - Mating |
-
|
|
|
Contact Finish - Post |
Tin
|
|
|
Contact Material |
Brass
|
|
|
Insulation Material |
Polybutylene Terephthalate (PBT)
|
|
|
Features |
Mounting Flange
|
|
|
Operating Temperature |
-30°C ~ 105°C
|
|
|
Ingress Protection |
-
|
|
|
Material Flammability Rating |
-
|
|
|
Insulation Color |
Black
|
|
|
Current Rating (Amps) |
Varies by Wire Gauge
|
|
|
Voltage Rating |
-
|
|
|
Mated Stacking Heights |
-
|
|
|
Contact Finish Thickness - Post |
-
|
|
|
Applications |
Automotive, General Purpose
|
|
|
Base Product Number |
174973 |
